Info

• Certifications and Testing:

  • Fire testing performed in accordance with EN 1363-1:1999 and UNI EN 1363-1:2001

  • Certified intumescent seals according to DIN 4102

  • Safety signage compliant with DIN 4844 and ISO 3864

  Structure:

  • Pickled steel, thickness 10/10

  • Double casing (internal and external shell)

  • Acid-resistant epoxy coating, baked in thermal tunnel at 200°C

  • Eco-friendly, high-resistance fireproof insulation

  • Internal shell resistant to corrosive substances

  Fire Safety:

  • Primary intumescent seal + secondary seal for protection from cold/hot fumes and dust

  • "Ignis-lock" system: automatic door closure in case of fire

  • Hinged doors with automatic closure and return

  • 2 certified safety valves, activated at 70 ±10°C, for vapor release

  • Ø100 mm connection collar for external extraction

  • Safety cylinder lock with key

  Internal Storage:

  • 3 removable tray shelves in electro-galvanized, epoxy-painted steel, height adjustable

  • Tray type, capacity 7 liters – load capacity 50 kg each

  • Bottom sump tray – 23 liters

  • Drip tray to collect condensation into the sump

  Additional Components:

  • Grounding clamp to prevent electrostatic discharge

  • Adjustable feet for leveling

  • Palletized base with front panel for easy handling

  • Safety signage included: flammable and no smoking

  Warranty:

  • Product liability insurance included for the entire useful life of the cabinet

  Dimensions:

  • External: 680 x 650 x 1985 mm (maximum depth: 740 mm)

  • Internal: 515 x 445 x 1685 mm

  • Internal volume: approx. 386 liters

  • Weight: 350 kg
