Info

Certifications:

• EN 14470-1 (fire resistance)

• UNI EN ISO 9001:2000 (quality control of painting process)

• DIN 4844 / ISO 3864 (safety signage)

• TÜV certified for each product

• CE Marking

Structure:

• Pickled and electro-galvanized steel

• Double casing (internal + external shell)

• Fireproof insulation with high-resistance materials

• Acid-resistant epoxy coating, electrostatically applied and baked at 200°C

Fire Safety:

• Ignis Lock System: patented automatic closing system in case of fire

• Intumescent seal + additional seal for hot and cold fumes

• Hinged door with self-closing mechanism

• 2 certified safety valves (Ø100 mm), automatic closing at 70 ±10°C

• Grounding clamp to prevent electrostatic discharge

• Included safety signage: flammable and no smoking

Internal Storage:

• 1 adjustable painted steel tray shelf – 7 L capacity – 50 kg load capacity

• 1 bottom sump tray – 10 L capacity for spill containment

External Structure:

• 4 adjustable feet

• Pre-configured for filtration/extraction system

• Usable volume: approx. 30 liters

Optional Accessories:

• Thermal device for automatic door closing at 50°C (non-electric)

• Wheeled trolley

• Filtration/extraction system

Dimensions:

• External: 595 x 510 x 600h mm

Warranty:

• Product liability insurance valid for the entire lifetime of the cabinet
