Info

• Certifications and Standards:

  • EN 14470-1 (Fire resistance – Type 90)

  • UNI EN 14727 (Laboratory storage furniture)

  • EN 1363-1:1999 / UNI EN 1363-1:2001 (Fire testing)

  • DIN 4102 (Intumescent seals)

  • DIN 4844 / ISO 3864 (Safety signage)

  • UNI EN ISO 9001:2000 (Quality control)

  • CE Marking

  Structure:

  • Pickled steel thickness 10/10, electro-galvanized

  • Acid-resistant epoxy powder coating, baked at 200°C

  • Double casing (internal and external) with eco-friendly fireproof insulation

  • Interiors resistant to corrosive substances

  • Intumescent seal + additional seal for insulation from cold/hot fumes and dust

  Fire Safety:

  • Automatic door closing (patented Ignis-lock system)

  • Hinged doors with self-closing mechanism

  • 2 certified safety valves (Ø100 mm), automatic closing at 70 ±10°C

  • Grounding clamp

  • Safety signage included

  Ventilation and Setup:

  • Natural ventilation with exhaust valves (top/bottom)

  • Ø100 mm connection collar for vapor extraction

  • Ready for extraction system installation

  Internal Storage:

  • 3 adjustable removable tray shelves in painted steel – capacity 14 L each – load capacity 80 kg

  • 1 bottom sump tray – 45 liters

  • Drip tray for condensation collection

  External Structure:

  • Adjustable feet for leveling

  • Palletized base with front panel

  • Easy Going System: allows short moves without forklifts

  • Lockable door with cylinder lock

  Insurance:

  • Product liability insurance for the entire lifetime of the cabinet (covers damage to people and property)

  Dimensions and Weight:

  • External dimensions: 1180 × 650 × 1985 mm

  • Maximum depth: 710 mm

  • Internal dimensions: 1015 × 445 × 1685 mm

  • Usable volume: approx. 761 liters

  • Storage capacity: approx. 160 liters

  • Weight: 490 kg
